Based on how your facility is laid out,
and how you intend to use the system
it must be decided where the hoist travel will best serve the needs of your facility.

Any place that you need to have the trolley turn from one section of track on to another section you will need a switch,
the switch must be placed 4 feet before the section of track you are turning onto in order to complete the switch.
Also when planning any curves or turns in the track, plan on starting the curve 4 feet before you want to finish it.

Here are links to the load charts for the various rail choices we offer,
in order of lightest rail to heaviest to help you find the best option.

Hanger Spacing Tables

• Click Here For US-401 Load Chart

• Click Here For Girder Rail Load Chart

• Click Here For US-1L Load Chart

• Click Here For US-1H Load Chart
